Locating the Serpentine Belt Diagram
For the 2010 Kia Forte, the serpentine belt diagram provides critical routing guidance to prevent accessory failure. Open the hood and inspect the radiator shroud or inner fender area; a factory sticker often displays the diagram. Always refer to the owner's manual, stored in your glove compartment, for a detailed illustration if not visible under the hood.
Standard Belt Path Description
The serpentine belt typically routes as follows on the common 2.0L Gamma MPI engine. Start at the crankshaft pulley; proceed counter-clockwise to:
- The alternator pulley
- The power steering pump pulley
- The air conditioning compressor pulley
- Over the tensioner pulley
- Back to the crankshaft pulley
Confirm this path using the diagram before any maintenance, as variations exist based on optional accessories or engine configurations.
Verifying and Replacing the Belt
Ensure the engine is off and cool. Apply the parking brake and remove the key. Trace the belt route against the diagram to avoid misalignment. To replace:
- Release tension using the tensioner pulley tool (e.g., socket wrench).
- Slide the old belt off, following the diagrammed path.
- Route the new belt identically, then tighten the tensioner.
Test briefly to check for squeaks or slipping, indicating incorrect routing.
Safety and Best Practices
Disconnect the battery to avoid accidental engine start. Wear gloves and eye protection, as belts can fray dangerously. If the diagram is missing, sketch the current path before removal to ensure accuracy. Professional consultation is recommended for uncertainties.
