Removing a glove box is straightforward with proper guidance. Follow these steps to safely complete the task without professional help.
Required Tools
- Phillips screwdriver
- Trim removal tool (plastic pry tool)
- Flashlight
- Container for screws
Safety Precautions
- Disconnect negative battery terminal to avoid airbag issues
- Wear safety glasses during disassembly
- Keep dashboard surfaces covered to prevent scratches
Removal Procedure
- Empty the glove box: Remove all contents and check for hidden items in side pockets.
- Access retention points:
- Fully open the glove box door
- Press inward on both sides of the compartment to clear stoppers
- Lower door to maximum open position (≈45° angle)
- Remove dampener arm:
- Locate piston/dampener on the right side
- Detach plastic clip using trim tool
- Slide arm off the ball stud
- Extract hinge pins:
- Identify white plastic hinge assemblies on both sides
- Simultaneously push hinge arms toward the center
- Lift glove box assembly downward to disengage
- Disconnect ancillary components:
- Unplug any cabin light wiring connectors
- Detach air ducting from HVAC inlet if present
Installation Notes
- Reverse removal sequence for reassembly
- Confirm hinge pins snap fully into receptacles
- Test door operation before reloading contents
