The 1995 Ford F-150 fuel pump circuit is primarily a 12V+ ignition-switched system with critical safety components. Understanding the wiring diagram is essential for correct installation.

Key Wiring Diagram Components

  • Main Power Source: Battery voltage supplied via the Fuel Pump Fuse (typically 20A) located in the engine compartment fuse/relay box.
  • Fuel Pump Relay: Controls power flow to the pump. Located in the engine compartment fuse/relay box. Key components:
    • Terminal 30: Fused Battery power (IN from fuse).
    • Terminal 87: Switched power output (OUT to inertia switch/pump).
    • Terminal 85: Relay coil ground (controlled by PCM).
    • Terminal 86: Relay coil power (+12V from PCM control circuit).
  • Inertia Safety Switch: An impact-sensitive cut-off switch (usually mounted on passenger side firewall/toe-board). Interrupts power to the pump in a collision. Connects the relay output to the pump wiring harness.
  • Pump Wiring (Tank Harness):
    • Power Supply Wire: Pink/Black stripe or Red/Light Green stripe (varies slightly by reference source). Carries switched +12V from inertia switch to pump.
    • Ground Wire: Black/Orange stripe or Black/Light Green stripe. Provides chassis ground for the pump motor. Essential to ensure this connection is clean and tight.
  • PCM Control: Powers the relay coil (Terminal 86) and briefly energizes the pump on key-on for priming. Also provides sustained power while cranking and with engine running.

Verifying Circuit Operation (Simplified Test Points)

  • Always relieve fuel pressure first.
  • Check fuse condition and for +12V at the fuse with key off. Replace if needed.
  • Key-On Test: Listen briefly for the pump at key-on. If silent:
    • Verify +12V at the Fuel Pump Relay socket Terminal 30 (constant).
    • Confirm +12V at Terminal 86 (PCM controlled) while the key is in RUN or START (needs a helper).
    • Check ground at relay Terminal 85 to chassis.
    • Check +12V at the output of the inertia switch (pink/black or red/green wire side towards pump) during key-on prime. If missing here, check input to inertia switch and reset switch if tripped.
    • At Pump Harness: Probe the pump power wire (pink/black or red/green) during key-on to verify +12V from inertia switch. Probe the ground wire (black/orange or black/green) to chassis to confirm good continuity (near 0 ohms).
  • Replace the fuel pump only if power and ground at the pump harness connector are confirmed during the prime cycle.

Critical Note: Ensure pump assembly ground connection (tank to frame, engine to battery) and harness connectors are clean, tight, and corrosion-free. A bad ground is a common failure point.
